Model Year | 2025 |
---|---|
Options | Small Medium Large Extra Large |
Frame | Genius Alloy 6061 Integrated Suspension Technology Virtual 4 Link kinematic / Adjustable head angle Syncros Cable Integration System BB92 / UDH Interface / 12x148mm with 55mm Chainline |
Forks | ockShox Lyrik Air Rush RC Damper 15x110mm Maxle Stealth 44mm offset / Tapered steerer Comp & Reb. Adj. / 160mm travel |
Rear Derailleur | Sram NX eagle 12 speed |
Shifters | SRAM SX Eagle Trigger |
Chainset | SRAM SX Eagle DUB 55mm CL / 32T |
Bottom Bracket | SRAM DUB PF 92 MTB Wide / shell 41x92mm |
Freewheel | SRAM SX-PG1210 / 11-50 T |
Chain | SRAM CN SX Eagle |
Stem | Syncros AM 2.0 Syncros Cable Integration System 4° rise / 6061 Alloy / 31.8mm / 1 1/8" |
Handlebars | Syncros Hixon 2.0 Alloy 6061 D.B. 12mm Rise / back sweep 8° / 780mm Syncros Endurance lock-on grips |
Front Brake | Sram DB8, Sram Centerline CL Rotor 200mm |
Rear Brake | Sram DB8, Sram Centerline CL Rotor 180mm |
Rims | Syncros X-30S / 32H / 30mm / Sleeve Joint |
Front Hub | Formula CL-811 / 15x110mm |
Rear Hub | Formula CL-148S / 12x148mm |
Spokes | Stainless Black 15G / 1.8mm |
Tyres | Maxxis Minion DHF / 60TPI Foldable Tubeless Ready / EXO Front, Maxxis Dissector / 60TPI Foldable Tubeless Ready / EXO rear |
Seatpost | Syncros Duncan Dropper Post 1.5 31.6mm / S size 140mm / M size 160mm L size 170mm / XL size 200mm |
Miscellaneous | TracLoc Technology Rear Suspension & Dropper Remote 3 Rear Suspension modes |
Rear Shock | FOX FLOAT X NUDE PE EVOL Piggy Back Trunnion SCOTT custom w. travel / geo adj. 3 modes: Climb-Traction Control-Descend Custom large Air volume / Comp & Reb. Adj. Travel 150-100-Climb / T185X55mm |
As with any product, specification is subject to change without prior notification. You are advised to confirm current specification and availablity before buying.
